Goodrive350 series high-performance multifunction VFD
Function
Name
code
Encoder pulse
P24.18
filter width
Pulse reference
P24.19
filter width
Pulse number of
P24.20
pulse reference
Enable angle
compensation of
P24.21
synchronous
motor
Switchover
frequency
threshold of
P24.22
speed
measurement
mode
Synchronous
motor angle
P24.23
compensation
coefficient
Description
0: No filter
1: Filter
Bit3: Enable/disable pulse reference
frequency-division output filter
0: No filter
1: Filter
Bit4: Enable/disable pulse reference filter
0: No filter
1: Filter
Bit5: Pulse reference filter mode
0: Self-adaptive filter
1: Use P24.19 filter parameters
Bit6: Frequency- division output source setting
(valid only for incremental encoders)
0: Encoder signals
1: Pulse reference signals
Bits 7–15: Reserved
0–63
The filtering time is P24.18×0.25 μs. The value 0
or 1 indicates 0.25 μs.
0–63
The filtering time is P24.19×0.25 μs. The value 0
or 1 indicates 0.25 μs.
0–16000
0–1
0–630.00Hz
-200.0–200.0%
-255-
Function parameter list
Default
Modify
value
2
2
1024
0
1.00Hz
100.0%
