Goodrive350 series high-performance multifunction VFD
Function
Name
code
group 16
Fault severity
P11.47
group 17
Fault severity
P11.48
group 18
Fault severity
P11.49
group 19
Fault severity
P11.50
group 20
Action for fault
P11.51
pre-alarm
Frequency
P11.52 reserved for
exception
Fire mode
P11.53
function
Description
Group 13: Faults 59–62 (OT, F1-Er, F2-Er, F3-Er)
Group 14: Faults 63–66 (C1-Er, C2-Er, C3-Er,
E-CAT)
Group 15: Faults 67–70 (E-BAC, E-DEV, S-Err,
OtE1)
Group 16: Faults 71–75 (OtE2, E-EIP, E-PAO,
E-AI1)
Group 17: Faults 75–78 (E-AI2, E-AI3, Reserved,
Reserved)
Group 18: Faults 79–82 (Reserved, Reserved,
Reserved, Reserved)
Group 19: Faults 83–86 (Reserved, Reserved,
Reserved, Reserved)
Group 20: Faults 87–90 (Reserved, Reserved,
Reserved, Reserved)
0–4
0: Run at the set frequency
1: Run at the output frequency at the time of fault
2: Run at the frequency upper limit
3: Run at the frequency lower limit
4: Run at the frequency reserved for exception
0.00–630.00Hz
0–2
0: Invalid
1: Fire mode 1
2: Fire mode 2
When P11.53=0, the fire mode is invalid, and the
normal running mode is used. In this case, the
VFD stops when encountering a fault.
When the fire mode function is valid, the VFD runs
at the speed specified by P11.54.
When fire mode 1 is selected, the VFD always
runs except when the VFD has been damaged.
When fire mode 2 is selected, the VFD always
runs, but the VFD stops when encountering OUT1,
OUT2, OUT3, OC1, OC2, OC3, OV1, OV2, OV3,
or SPO.
Note: Terminal control must be used for a fire
-208-
Function parameter list
Default
Modify
value
○
0x0000
○
0x0000
○
0x0000
○
0x0000
○
0
○
0.00Hz
◎
0
