Goodrive350 series high-performance multifunction VFD Dimension drawings
C.3 VFD structure
Figure C-3 VFD structure diagram
C.4 Dimensions of AC 3PH 380V (-15%)–440V (+10%)
C.4.1 Wall mounting dimensions
D1 W2
W1
H1
H2
Figure C-4 Wall mounting diagram for 380V 1.5–37kW models
-381-
