Goodrive350 series high-performance multifunction VFD
Function
VFD state word 1
VFD state word 2
Address
1000 corresponding to 100.0% of the rated
current of the VFD)
Upper limit of the braking torque (0–3000, 1000
2008H corresponding to 100.0% of the rated current of
the motor)
Special control command word:
Bit0–1: =00: Motor 1
Bit2: =1 Torque control disabled =0: Torque
control cannot be disabled
2009H
Bit3: =1 Power consumption reset to 0
=0: Power consumption not reset
Bit4: =1 Pre-excitation =0: Pre-excitation
disabled
Bit5: =1 DC braking =0: DC braking disabled
Virtual input terminal command, range: 0x000–
0x3FF
200AH
Corresponding to S8/S7/S6/S5/HDIB/HDIA/S4/
S3/ S2/S1
Virtual output terminal command, range: 0x00–
200BH 0x0F
Corresponding to local RO2/RO1/HDO/Y1
Voltage setting (used when V/F separation is
implemented)
200CH
(0–1000, 1000 corresponding to 100.0% of the
rated voltage of the motor)
AO output setting 1 (-1000–+1000, 1000
200DH
corresponding to 100.0%)
AO output setting 2 (-1000–+1000, 1000
200EH
corresponding to 100.0%)
0001H: Forward running
0002H: Reverse running
0003H: Stopped
2100H
0004H: Faulty
0005H: POFF
0006H: Pre-excited
Bit0: =0: Not ready to run =1: Ready to run
2101H Bi1–2: =00: Motor 1
=10: Motor 3
Data description
=01: Motor 2
=10: Motor 3 =11: Motor 4
=01: Motor 2
=11: Motor 4
-318-
Communication
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R
R
