INVT Goodrive350 Series Operation Manual page 270

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Relay RO5
P26.23
switch-on delay
Relay RO5
P26.24
switch-off delay
Relay RO6
P26.25
switch-on delay
Relay RO6
P26.26
switch-off delay
Relay RO7
P26.27
switch-on delay
Relay RO7
P26.28
switch-off delay
Relay RO8
P26.29
switch-on delay
Relay RO8
P26.30
switch-off delay
Relay RO9
P26.31
switch-on delay
Relay RO9
P26.32
switch-off delay
Relay RO10
P26.33
switch-on delay
Relay RO10
P26.34
switch-off delay
AO2 output
P26.35
selection
AO3 output
P26.36
selection
Lower limit of
P26.38
AO2 output
Corresponding
P26.39 AO2 output of
lower limit
Upper limit of
P26.40
AO2 output
Corresponding
P26.41 AO2 output of
upper limit
Description
The same with P06.14
Above function codes define the relation between
output value and analog output. When the output
value exceeds the set max./min. output range, the
upper/low limit of output will be adopted during
calculation.
When analog output is current output, 1mA
corresponds to 0.5V voltage. In different
applications, 100% of output value corresponds to
different analog outputs.
-261-
Function parameter list
Default
Modify
value
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0
○
0
○
0.0%
○
0.00V
○
100.0%
○
10.00V
