5.4.6 Editing parameters in parameter groups

You can choose Menu > Parameter groups, enter a specific function group and then a specific
function code, and then press
interface. After entering edit interface, set the parameter from low bit to high bit, and the bit under
setting will be highlighted. Press
(this operation is valid until the parameter value exceeds the max. value or min. value); press
to shift the editing bit. After parameters are set, press
parameters and return to the previous menu; press
and return to the previous menu.
16:02:35 Fwd Local Ready
P00.00: Speed Ctrl Run Cmd
P00.01: Run Cmd Channel
P00.02: Comm Cmd Channel
P00.03: Max Output Freq
P00.04: RunFreq Up Limit
P00.05: RunFreq Low Limit
Back Edit
In the parameter edit interface, the "Auth" field on the top right indicates whether this parameter can
be modified or not.
"√" indicates the set value of this parameter can be modified under the present state.
"×" indicates the set value of this parameter cannot be modified under the present state.
"Present" indicates the present value.
"Default" indicates the default value of this parameter.

5.4.7 Monitoring states

You can choose Menu > State monitoring > State monitoring parameter, enter a specific function
group and then a specific function code, and press
state monitoring interface. After entering the state monitoring interface, the actual parameter value
will be displayed in real time, this value is the actually detected value which cannot be modified.
In the state monitoring interface, you can press
menu.
key,
key or
GD350 Present：50.00
Max Output Freq
Max
Min
Default
Sele
Figure 5-16 Editing parameters in parameter groups
key or
key to increase or decrease theparameter value
to maintain the original parameter value
Auth: √
Hz
050.00
: 630.00
: 50.00
: 50.00
Back Home OK
key,
key or
