Goodrive350 series high-performance multifunction VFD
Set
value
4
5
6 Frequency level detection FDT1
7 Frequency level detection FDT2
8 Frequency reached
9 Running in zero speed
10 Reach upper limit frequency
11 Reach lower limit frequency
12
13
14 Overload pre-alarm
15 Underload pre-alarm
16 Simple PLC state completed
17 Simple PLC cycle completed
Virtual terminal output of
23 Modbus/Modbus TCP
Virtual terminal output of
24 POROFIBUS/CANopen/DeviceNet
Virtual terminal output of Ethernet
25
26 DC bus voltage established
Function
In jogging
VFD fault
Ready to run
In pre-exciting
communication
communication
communication
Description
Output ON signal when there is frequency output
during jogging
Output ON signal when VFD fault occurred
Refer to P08.32 and P08.33
Refer to P08.34 and P08.35
Refer to P08.36
Output ON signal when the VFD output frequency
and reference frequency are both zero.
Output ON signal when the running frequency
reaches upper limit frequency
Output ON signal when the running frequency
reached lower limit frequency
Main circuit and control circuit powers are
established, the protection functions do not act;
when the VFD is ready to run, output ON signal.
Output ON signal during pre-exciting of the VFD
Output ON signal after the pre-alarm time elapsed
based on the pre-alarm threshold; see P11.08–
P11.10 for details.
Output ON signal after the pre-alarm time elapsed
based on the pre-alarm threshold; see P11.11–
P11.12 for details.
Output signal when current stage of simple PLC is
completed
Output signal when a single cycle of simple PLC
operation is completed
Output corresponding signal based on the set
value of Modbus/Modbus TCP; output ON signal
when it is set to 1, output OFF signal when it is set
to 0
Output corresponding signal based on the set
value of POROFIBUS/CANopen/DeviceNet;
output ON signal when it is set to 1, output OFF
signal when it is set to 0
Output corresponding signal based on the set
value of Ethernet; output ON signal when it is set
to 1, output OFF signal when it is set to 0.
Output is valid when the bus voltage is above the
-105-
