Goodrive350 series high-performance multifunction VFD
4.4.2 Wiring diagram of control circuit for parallel products
15-core serial port
cable length
Optical fiber cable
length
Master–
Master
Slave 1
About
About
960mm
1910mm
About
About
1000mm
1500mm
Master–
Master–
Slave 2
Slave 3
About
About
3220mm
3220mm
About
About
2600mm
3700mm
-31-
Installation guidelines
Master–
Master–
Slave 4
Slave 5
About
About
4740mm
4740mm
About
About
4800mm
5900mm
