Goodrive350 series high-performance multifunction VFD
Function
code
P05.01– Digital input function
P05.06
Amplitude of wobbling
P08.15
P08.16 Amplitude of jump frequency
Wobbling frequency rise
P08.17
P08.18 Wobbling frequency fall time 0.1–3600.0s

5.5.17 Local encoder input

The VFD supports pulse count function by inputting the count pulse from HDI high-speed pulse port.
When the actual count value is no less than the set value, digital output terminal will output
count-value-reached pulse signal, and the corresponding count value will be zeroed out.
Function
code
P05.00
HDIA high-speed pulse input
P05.38
HDIB high-speed pulse input
P05.44
P18.00 Actual frequency of encoder -999.9–3276.7Hz
P20.15 Speed measurement mode
Name
selection
frequency
time
Name
HDI input type
function
function selection
Description
26: Wobbling frequency pause (stop at
current frequency)
27: Wobbling frequency reset (revert to
center frequency)
0.0–100.0% (relative to set frequency)
0.0–50.0% (relative to amplitude of
wobbling frequency)
0.1–3600.0s
Description
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0: Set input via frequency
1: Reserved
2: Input via encoder, used in combination
with HDIB
0: Set input via frequency
1: Reserved
2: Input via encoder, used in combination
with HDIA
0: PG card
1: local; realized by HDIA and HDIB;
supports incremental 24V encoder only
-120-
Basic operation guidelines
Default
value
/
0.0%
0.0%
5.0s
5.0s
Default
value
0x00
0
0
0.0Hz
0
