Goodrive350 series high-performance multifunction VFD
Indicator
LED2
LED3
LED4
A.6.4 CANopen communication

communication card (EC-TX511)

The EC-TX505/511 communication card is user-friendly, adopting spring terminals.
3-pin spring terminal
1 2 3
Terminal resistor switch function description
Terminal resistor switch
Definition
Network connection
status indicator
Network
communication status
indicator
Power indicator
card
Pin
1
2
3
Position
Left
Right
properly connected to the control board (the
period is 1s, on for 0.5s, and off for the other
0.5s).
Off: The expansion card is disconnected from the
control board.
On: The physical connection to the upper
computer is normal.
Off: The upper computer is disconnected.
On: There is data exchange with the upper
computer.
Off: There is no data exchange with the upper
computer.
On: The control board feeds power to the
communication card.
(EC-TX505) and
Function
CANH CANopen bus high level signal
CANG CANopen bus shielding
CANL CANopen bus low level signal
Function
CAN_H and CAN_L are not
OFF
connected to a terminal resistor.
CAN_H and CAN_L are connected to
ON
a terminal resistor of 120 Ω.
-351-
Expansion cards
Function
CAN master/slave
Description
Description
control
