Goodrive350 series high-performance multifunction VFD
Function
Name
code
Winding/
P90.01
unwinding mode
Reel mechanical
P90.02
transmission rate
Max. linear
P90.03
speed
Input source of
P90.04
linear speed
Linear speed set
P90.05
through keypad
Diameter of main
P90.06
traction
Main traction
P90.07
drive ratio
Linear speed
P90.08
ACC time
Linear speed
P90.09
DEC time
P90.10 Tension setting
Description
0: Winding
1: Unwinding
Note: The motor forward rotation direction is the
winding direction. When using the tension control
mode, check whether the motor rotation direction
is correct in the winding mode; if not, change the
rotation direction by swapping two phase wires of
the motor. After the rotation direction is corrected,
the winding mode can be switched to the
unwinding mode by setting P90.01 to 1 or
changing the winding/unwiding switchover
terminals.
0.01–600.00
=Motor rotation speed/Reel rotation speed=Reel
diameter/Motor shaft diameter
0.0–6000.0 m/min
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI
5: Main traction encoder frequency-division input
0.0–100.0%
0.0–6000.0mm
0.000–60.000
0.00–600.00s
0.00–600.00s
0x00–0x14
Ones place: Tension setting source
0: Keypad
1: AI1
2: AI2
3: AI3
-269-
Function parameter list
Default Modify
○
0
○
1.00
1000.0
○
m/min
◎
0
○
20.0%
○
99.0mm
○
1.000
○
0.00s
○
0.00s
◎
0x00
