Goodrive350 series high-performance multifunction VFD
A.6.2 PROFIBUS-DP communication card (EC-TX503)
CN1 is a 9-pin D-type connector, as shown in the following figure.
Connector pin
1
2
3
4
5
6
7
8
9
Housing
+5V and GND_BUS are bus terminators. Some devices, such as the optical transceiver (RS485),
may need to obtain power through these pins.
On some devices, the transmission and receiving directions are determined by RTS. In normal
applications, only A-Line, B-Line, and the shield layer need to be used.
Indicator definition
Indicator
LED1 State indicator
-
-
B-Line
RTS
GND_BUS
+5V BUS
-
A-Line
-
SHLD
Name
On: The expansion card is establishing a connection with the
control board.
Blinking periodically: The expansion card is properly connected
to the control board (the period is 1s, on for 0.5s, and off for the
other 0.5s).
Off: The expansion card is disconnected from the control
5 4 3 2 1
9 8 7 6
Data+ (twisted pair 1)
Request transmission
Isolated power supply of 5 V DC
Data- (twisted pair 2)
PROFIBUS cable shielding line
Description
-349-
Expansion cards
Description
Unused
Unused
Isolation ground
Unused
Unused
