5.5.10 Analog output

The VFD carries one analog output terminal (0–10V/0–20mA) and one high-speed pulse output
terminal. Analog output signals can be filtered separately, and the proportional relation can be
adjusted by setting the max. value, min. value, and the percentage of their corresponding output.
Analog output signal can output motor speed, output frequency, output current, motor torque and
motor power at a certain proportion.
0
1
2
3
.
.
.
.
P06.00
.
(HDO output type)
.
0
19
1
20
0: Open collector high-speed
P06.00 pulse output
1: Open-collector output
AO output relationship description:
(The min. value and max. value of the output correspond to 0.% and 100.00% of the pulse or analog
default output. The actual output voltage or pulse frequency corresponds to the actual percentage,
which can be through function codes.)
