INVT Goodrive350 Series Operation Manual page 185

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Output terminal
P06.05
polarity selection
P06.06 Y switch-on delay This function code defines the corresponding
Description
29: STO action
30: Positioning completed
31: Spindle zeroing completed
32: Spindle scale-division completed
33: In speed limit
34: Virtual terminal output of
EtherCAT/PROFINET/EtherNet IP communication
35: Reserved
36: Speed/position control switchover completed
37: Any frequency reached
38–40: Reserved
41: Y1 from the programmable card
42: Y2 from the programmable card
43: HDO from the programmable card
44: RO1 from the programmable card
45: RO2 from the programmable card
46: RO3 from the programmable card
47: RO4 from the programmable card
48: EC PT100 detected OH pre-alarm
49: EC PT1000 detected OH pre-alarm
50: AI/AO detected OH pre-alarm
51: Stopped or running at zero speed
52: Disconnection detected in tension control
53: Roll diameter setting reached
54: Max. roll diameter reached
55: Min. roll diameter reached
56: Fire control mode enabled
57–63: Reserved
This parameter specifies the polarity of output
terminals.
When the bit is set to 0, input terminal polarity is
positive;
When the bit is set to 1 input terminal polarity is
negative.
BIT3 BIT2
RO2 RO1
Setting range: 0x00–0xF
-176-
BIT1 BIT0
HDO Y1
Function parameter list
Default
Modify
value
○
0x00
○
0.000s
