INVT Goodrive350 Series Operation Manual page 103

Goodrive350 series high-performance multifunction VFD
Function
code
P06.17 Lower limit of AO1 output
Corresponding AO1 output of
P06.18
P06.19 Upper limit of AO1 output
Corresponding AO1 output of
P06.20
P06.21 AO1 output filter time
P06.22–
P06.26
P06.27 Lower limit of HDO output
Corresponding HDO output of
P06.28
P06.29 Upper limit of HDO output
Corresponding HDO output of
P06.30
P06.31 HDO output filter time
Name
lower limit
upper limit
Reserved
lower limit
upper limit
Description
communication
28: AO1 from the programmable card
29: AO2 from the programmable card
30: Rotational speed (100%
corresponds to twice the motor rated
synchronous speed)
31: Output torque (Actual value, 100%
corresponds to twice the motor rated
torque)
32: AI/AO temperature detection output
33–63: Reserved
Note:
When the output comes from the
programmable card (28–29), if the card
is a Codesys programmable card,
P27.00 must be set to 1.
When AO1 is of the current output type,
100% corresponds to 20mA; when AO1
is of the voltage output type, 100%
corresponds to 10V; 100% of HDO
corresponds to the output of P06.30.
-300.0%–P06.19
0.00V–10.00V
P06.17–300.0%
0.00V–10.00V
0.000s–10.000s
/
-300.0%–P06.29
0.00–50.00kHz
P06.27–300.0%
0.00–50.00kHz
0.000s–10.000s
-94-
Basic operation guidelines
Default
value
0.0%
0.00V
100.0%
10.00V
0.000s
/
0.0%
0.0kHz
100.0%
50.00kHz
0.000s
