P08--Enhanced Functions - INVT Goodrive350 Series Operation Manual

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Bus voltage of
P07.53
the 2nd-last fault
Max. temperature
P07.54 of the 2nd-last
fault
Input terminal
P07.55 state of the
2nd-last fault
Output terminal
P07.56 state of the
2nd-last fault
P08––Enhanced functions
Function
Name
code
Acceleration
P08.00
time 2
Deceleration
P08.01
time 2
Acceleration
P08.02
time 3
Deceleration
P08.03
time 3
Acceleration
P08.04
time 4
Deceleration
P08.05
time 4
Running
P08.06 frequency of
jogging
Acceleration time
P08.07
of jogging
Deceleration time
P08.08
of jogging
P08.09 Jump frequency 1 When the set frequency is within the range of jump 0.00Hz
Description
0.0–2000.0V
-20.0–120.0° C
0x0000–0xFFFF
0x0000–0xFFFF
Description
See P00.11 and P00.12 for detailed definitions.
Goodrive350 series VFD defines four groups of
acceleration/deceleration time, which can be
selected by multi-function digital input terminal
(P05 group). The acceleration/deceleration time of
the VFD is the first group by default.
Setting range: 0.0–3600.0s
This function code is used to define the reference
frequency of the VFD during jogging.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
Jogging acceleration time is the time needed for
the VFD to accelerate from 0Hz to Max. output
frequency (P00.03).
Jogging deceleration time is the time needed from
decelerating from Max. output frequency (P00.03)
to 0Hz.
Setting range: 0.0–3600.0s
-175-
Function parameter list
Default
Modify
value
●
0.0V
●
0.0° C
●
0
●
0
Default
Modify
value
Depends
○
on model
Depends
○
on model
Depends
○
on model
Depends
○
on model
Depends
○
on model
Depends
○
on model
○
5.00Hz
○
Depends
on model
○
○
