C.5.3 Floor mounting dimensions
W2
H1
Figure C-19 Floor mounting diagram for 660V 250–355kW models
W1
W2
H1
Figure C-20 Floor mounting diagram for 660V 400–630kW models
Table C–6 Floor mounting dimensions of 660V VFD models (unit: mm)
VFD model
W1
250kW–355kW
750
400kW–630kW
620
W4
W2
3- ø13.0
H2
W2
3- ø22.0
H2
W2
W3
230
714
230
572
D1
D1
W4
H1
H2
680
1410
1390
/
1700
1678
-388-
Dimension drawings
W1
W3
D2
D2
W3
D2
D2
Mounting
D1
D2
hole
380
150
Ø 13/12
560
240
Ø 22/12
6- ø12.0
6- ø12.0
Fixing
screw
M12/M10
M20/M10
