Goodrive350 series high-performance multifunction VFD
you can enter the interface only with the correct user password. For the factory parameters,
you need to enter the correct factory password to enter the interface. (You are not advised to
modify the factory parameters. Incorrect parameter setting may cause operation exceptions or
even damage to the VFD.) If password protection is not in locked state, you can change the
password any time. You can set P07.00 to 0 to cancel the user password. When P07.00 is set
to a non-zero value during power-on, parameters are prevented from being modified by using
the user password function. When you modify function parameters through serial
communication, the user password protection function is also applicable and compliant with the
same rule.
P00––Basic functions
Function
Name
code
Speed control
P00.00
mode
Channel of
P00.01 running
commands
Communication
P00.02 mode of running
commands
Max. output
P00.03
frequency
Upper limit of
P00.04 running
frequency
Description
0: Sensorless vector control (SVC) mode 0
1: SVC 1
2: SVPWM
3: FVC
Note: To select 0, 1, or 3 as the control mode,
enable the VFD to perform motor parameter
autotuning first
0: Keypad
1: Terminal
2: Communication
0: Modbus/Modbus TCP
1: PROFIBUS/CANopen/DeviceNet
2: Ethernet
3: EtherCAT/PROFINET/EtherNet IP
4: Programmable card
5: Wireless communication card
6: Reserved
Note: The Modbus TCP communication mode of
option 0, and options 1, 2, 3, 4 and 5 are extended
functions which are applicable with corresponding
cards.
Used to set the maximum output frequency of the
VFD. It is the basis of frequency setting and the
acceleration/deceleration.
Setting range: Max. (P00.04, 10.00)–630.00Hz
Used to set the upper limit of VFD output
frequency. This value cannot be more than the
maximum output frequency.
-137-
Function parameter list
Default
Modify
value
◎
2
○
0
○
0
◎
50.00Hz
◎
50.00Hz
