INVT Goodrive350 Series Operation Manual page 107

Goodrive350 series high-performance multifunction VFD
Setting
36 Command switches to keypad
Command switches to
37
Command switches to
38
communication
39 Pre-exciting command
Zero out power consumption
40
Maintain power consumption
41
Source of upper torque limit
42
switches to keypad
43 Position reference point input Valid only for S1, S2, and S3.
44 Disable spindle orientation
Spindle zeroing/local position
45
Spindle zero position selection
46
Spindle zero position selection
47
Spindle scale division
48
Spindle scale division
49
Spindle scale division
50
Position/speed control
51
switchover terminal
52 Disable pulse input
53 Clear position deviation
Function
terminal
quantity
quantity
zeroing
1
2
selection 1
selection 2
selection 3
When this terminal is valid, the running command
channel will switch to keypad compulsorily. If this
function becomes invalid, the running command channel
will revert to the original state.
When this terminal is valid, the running command
channel will switch to terminal compulsorily. If this
function becomes invalid, the running command channel
will revert to the original state.
When this terminal is valid, the running command
channel will switch to communication compulsorily. If this
function becomes invalid, the running command channel
will revert to the original state.
When this terminal is valid, motor pre-exciting will be
started until this terminal becomes invalid.
After this command becomes valid, the power
consumption quantity of the VFD will be zeroed out.
When this command is valid, current operation of the
VFD will not impact the power consumption quantity.
When this command is valid, the upper limit of the torque
will be set by keypad.
Spindle orientation is invalid.
Spindle positioning is triggered.
Spindle zero position selection 1.
Spindle zero position selection 2.
Spindle scale division selection 1.
Spindle scale division selection 2.
Spindle scale division selection 3.
Terminal for switching between position control and
speed control.
Pulse input is invalid when the terminal is valid.
Used to clear the input deviation of position loop.
-98-
Basic operation guidelines
Description
