INVT Goodrive350 Series Operation Manual page 401

Goodrive350 series high-performance multifunction VFD
Table C–9 Dimensions of closely mounting parallel 380V VFDs (Unit: mm)
VFD model W1
560–630kW 1447
710–1000kW 1323
1200–1500kW 1956
2000kW 2589
2500kW 3222
3000kW 3855
Table C–10 Dimensions of closely mounting parallel 660V VFDs (Unit: mm)
VFD model W1
710kW 1447
800–1200kW 1323
1500kW 1956
2000–
2589
2500kW
3000kW 3222
W2 W3 W4
1383 1417 13
1253 1288 13
1886 1921 13
2519 2554 13
3152 3187 13
3785 3820 13
W2 W3 W4
1383 1417 13
1253 1288 13
1886 1921 13
2519 2554 13
3152 3187 13
H1 H2
1419.9 1356 442.5 429.5
1900 - 636.3 625.5
1900 - 636.3 625.5
1900 - 636.3 625.5
1900 - 636.3 625.5
1900 - 636.3 625.5
H1 H2 D1
1419.9 1356 442.5
1900 - 636.3
1900 - 636.3
1900 - 636.3
1900 - 636.3
-392-
Dimension drawings
D1 D2 D3
350
570
570
570
570
570
D2 D3
429.5 350
625.5 570
625.5 570
625.5 570
625.5 570
Mounting
hole
Ø12
Ø12
Ø12
Ø12
Ø12
Ø12
Mounting
hole
Ø 12
Ø 12
Ø 12
Ø 12
Ø 12
