C.4.3 Floor mounting dimensions
W4
W2
H1
Figure C-12 Floor mounting diagram for 380V 220–315kW models
W1
W2
H1
Figure C-13 Floor mounting diagram for 380V 355–500kW models
Table C–3 Floor mounting dimensions of 380V VFD models (unit: mm)
VFD model
220kW–315kW
355kW–500kW
W2
3- ø13.0
H2
W2
3- ø22.0
H2
W1 W2 W3
750 230 714
620 230 572
D1
D1
W4 H1 H2
680 1410 1390
- 1700 1678
-385-
Dimension drawings
W1
W3
D2
D2
W3
D2
D2
Mounting
D1 D2
hole
380 150 Ø 13/12 M12/M10
560 240 Ø 22/12 M20/M10
6- ø12.0
6- ø12.0
Fixing
screw
