INVT Goodrive350 Series Operation Manual page 109

Goodrive350 series high-performance multifunction VFD
Setting
75 Tension control pre-drive
Disable roll diameter
76
77 Clear alarm display
Manual braking of tension
78
Trigger forced feeding
79
80 Initial roll diameter 1
81 Initial roll diameter 2
82 Trigger fire mode control
Switch tension PID
83
84–95
Related parameter list:
Function
code
P05.00
P05.01 Function of S1 terminal
P05.02 Function of S2 terminal
P05.03 Function of S3 terminal
P05.04 Function of S4 terminal
P05.05 Function of HDIA terminal
Function
calculation
control
interrupt
parameters
Reserved
Name
HDI input type
If the terminal is valid when the tension control function is
enabled, tension control pre-drive is performed.
If the terminal is valid when the tension control function is
enabled, roll diameter calculation is disabled.
Used to clear the alarm display when the tension control
function is enabled.
If the terminal is valid when the tension control function is
enabled, manual braking is activated.
If the terminal is valid when the tension control function is
enabled, a feeding interrupt signal is triggered forcibly.
Used to select different initial roll diameters by combining
with the initial roll diameter 2 when the tension control
function is enabled.
Used to select different initial roll diameters by combining
with the initial roll diameter 1 when the tension control
function is enabled.
In fire mode, if the terminal is valid, the fire mode control
signal is triggered.
Used to switch two PID parameter groups when the
tension control function is enabled. The first group is
used by default. If the terminal is valid, the second group
is used.
Description
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0: No function
1: Forward running
2: Reverse running
3: 3-wire control/Sin
4: Forward jogging
5: Reverse jogging
-100-
Basic operation guidelines
Description
/
Default
value
0x00
1
4
7
0
0
