Goodrive350 series high-performance multifunction VFD Dimension drawings
C.6.2 Dimensions with the close mounting method
Note: Using the close mounting method for parallel VFDs will have a smaller size, which affects the
internal air intake of the product, but meets the product cooling effect.
Figure C-23 Parallel mounting diagram for 380V 560–630kW and 660V 710kW
Figure C-24 Parallel mounting diagram for 380V 710–3000kW and 660V 800–3000kW
-391-
