Goodrive350 series high-performance multifunction VFD
4. Fix all the cables outside the VFD mechanically if allowed.

4.4 Standard wiring of control circuit

4.4.1 Wiring diagram of basic control circuit

Forward running
Forward jogging
Fault reset
(external)
Safety
switch
S2
S1
Open circuit
Safety
controller
Note: If wire-passing board outlet space is insufficient when all terminals on the control board are
wired, cut the knock-out hole on the lower cover for wire outlet. If a dangerous situation occurs when
the knock-out hole is cut for a purpose but not wire outlet, we will not bear any responsibility.
NG
The screw is
not fastened.
Figure 4-17 Screw installation diagram
S1
S2
S3
S4
HDIA
HDIB
COM
PW
+24V
PE
+10V
AI1
AI2
GND
PE
-10V
Safety
input
H1
H2
+24V
Safety state
feedback
Figure 4-18 Wiring diagram of control circuit
Y
The screw is
fastened.
VFD
SW2
V
SW3
Power used for
ON OFF
frequency setting
Multifunction
analog input
-29-
Installation guidelines
AO1
Analog output
0-10V/0-20mA
I
GND
Y1
Y1
CME output
HDO
Optional between high-
speed pulse output and
COM
open collector output
485+
RS485
485- communication
PE
RO1A
Relay 1
RO1B
output
RO1C
RO2A
Relay 2
RO2B
output
RO2C
