INVT Goodrive350 Series Operation Manual page 296

Goodrive350 series high-performance multifunction VFD
Fault
Fault type
code
the expansion card
in card slot 2
[65] Communication
timeout occurred to
C3-Er
the expansion card
in card slot 3
[29] PROFIBUS card
E-DP communication
timeout fault
[30] Ethernet card
E-NET communication
timeout fault
[31] CANopen card
E-CAN communication
timeout fault
[57] PROFINET card
E-PN communication
timeout fault
[66] EtherCAT card
E-CAT communication
timeout fault
Possible cause
card slot 2
There is no data
transmission in interfaces of
card slot 3
There is no data
transmission between the
communication card and the
host controller (or PLC).
There is no data
transmission between the
communication card and the
host controller.
There is no data
transmission between the
communication card and the
host controller (or PLC)
There is no data
transmission between the
communication card and the
host controller (or PLC)
There is no data
transmission between the
communication card and the
host controller (or PLC)
-287-
Troubleshooting
Corrective measures
Stabilize the expansion card
interfaces after power down,
and confirm whether fault still
occurs at next power-on;
Check whether the insertion
port is damaged, if yes, replace
the insertion port after power
down
Confirm whether the expansion
card inserted can be supported;
Stabilize the expansion card
interfaces after power down,
and confirm whether fault still
occurs at next power-on;
Check whether the insertion
port is damaged, if yes, replace
the insertion port after power
down
Check whether the
communication card wiring is
loose or dropped.
Check whether the
communication card wiring is
loose or dropped.
Check whether the
communication card wiring is
loose or dropped.
Check whether the
communication card wiring is
loose or dropped.
Check whether the
communication card wiring is
loose or dropped
