Goodrive350 series high-performance multifunction VFD
Function
Name
code
FWD rotation
frequency upper
P03.16 limit set through
keypad in torque
control
REV rotation
frequency upper
P03.17 limit set through
keypad in torque
control
Setting source of
P03.18 electromotive
torque upper limit
Setting source of
P03.19 braking torque
upper limit
Description
Note: For these settings, 100% corresponds to the
max. frequency.
Used to specify frequency limits. 100%
corresponds to the max. frequency. P03.16
specifies the upper-limit frequency when
P03.14=1; P03.17 specifies the upper-limit
frequency when P03.15=1.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET/EtherNet IP
communication
10: Programmable card
11: Reserved
Note: For these settings, 100% corresponds to the
motor rated current.
0: Keypad (P03.21)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET/EtherNet IP
-154-
Function parameter list
Default
Modify
value
○
50.00Hz
○
50.00Hz
○
0
○
0
