P10––Simple PLC and multi-step speed control
Function
Name
code
Simple PLC
P10.00
mode
Simple PLC
P10.01
memory selection
P10.02 Multi-step speed 0 Frequency setting range for steps from step 0 to
Running time of
P10.03
step 0
P10.04 Multi-step speed 1
Description
0.000–10.000s
/
0.00–10.00s
0.00–10.00s
0.00Hz–P09.21
P09.20–P00.04
/
Description
0: Stop after running once; the VFD stops
automatically after running for one cycle, and it can
be started only after receiving running command.
1: Keep running in the final value after running
once; The VFD keeps the running frequency and
direction of the last section after a single cycle.
2: Cyclic running; the VFD enters the next cycle
after completing one cycle until receiving stop
command and stops.
0: No memory after power down
1: Memory after power down; PLC memories its
running stage and running frequency before power
down.
step 15: -300.0–300.0%, 100% corresponds to
Max. output frequency (P00.03).
Running time setting range for steps from step 0 to
-198-
Function parameter list
Default
Modify
value
○
0.000s
/ /
○
0.90s
○
0.00s
○
5.00Hz
○
10.00Hz
/ /
Default
Modify
value
○
0
○
0
○
0.0%
○
0.0s(min)
○
0.0%
