P93--Tension Control Status Viewing - INVT Goodrive350 Series Operation Manual

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Stop braking
P92.14
frequency
P92.15 Stop braking time 0.0–600.0s
P93––Tension control status viewing
Function
Name
code
Actual control
P93.00
mode
Actual winding/
P93.01
unwinding mode
Initial roll
P93.02
diameter
Reset roll
P93.03
diameter
Roll diameter
P93.04
change rate
Present roll
P93.05
diameter
Roll diameter for
P93.06 linear speed
calculation
P93.07 Set linear speed 0.0–6000.0 m/min
Present linear
P93.08
speed
P93.09 Main reference 0.00–600.00Hz
Description
Tens place: Alarm mode
0: Stop in enabled stop mode without reporting an
alarm
1: Report an alarm and coast to stop
Hundreds place: Roll diameter memory function of
feeding interrupt
0: Disable
1: Enable
0.00–300.00Hz
Description
0–3
0: Invalid tension control
1: Close-loop tension speed control
2: Open loop tension torque control
3: Close-loop tension torque control
0–1
0: Winding
1: Unwinding
0.0–5000.0mm
0.0–5000.0mm
0.00–655.35 mm/s
0.0–5000.0mm
0.0–5000.0mm
0.0–6000.0 m/min
-277-
Function parameter list
Default Modify
○
1.50Hz
○
0.0s
Default Modify
●
0
●
0
●
0.0mm
●
0.0mm
0.00
●
mm/s
●
0.0mm
●
0.0mm
0.0
●
m/min
0.0
●
m/min
●
0.00 Hz
