Goodrive350 series high-performance multifunction VFD
Function
code
Speed control
P00.00
Enabling torque
P03.32
Torque setting
P03.11
Torque set through
P03.12
Torque reference
P03.13
filter time
Setting source of
FWD rotation
P03.14 frequency upper
limit in torque
Name
0: Sensorless vector control (SVC) mode 0
1: SVC 1
2: SVPWM
3: FVC
mode
Note: To select 0, 1, or 3 as the control mode,
enable the VFD to perform motor parameter
autotuning first
0: Disable
control 1: Enable
0–1: Keypad (P03.12)
2: AI1
3: AI2
4: AI3
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus/Modbus TCP communication
8: PROFIBUS/CANopen/DeviceNet
method communication
9: Ethernet communication
10: Pulse frequency HDIB
11: EtherCAT/PROFINET/EtherNet IP
communication
12: Programmable card
Note: For these settings, 100% corresponds to
the motor rated current.
-300.0%–300.0% (of the motor rated current)
keypad
0.000–10.000s
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus/Modbus TCP communication
control
7: PROFIBUS/CANopen/DeviceNet
communication
8: Ethernet communication
Description
-70-
Basic operation guidelines
Default
value
2
0
0
50.0%
0.010s
0
