INVT Goodrive350 Series Operation Manual page 414

Goodrive350 series high-performance multifunction VFD
VFD model
GD350-022G-4
GD350-030G-4
GD350-037G-4
GD350-045G-4
GD350-055G-4
GD350-075G-4
GD350-090G-4
GD350-110G-4
GD350-132G-4
GD350-160G-4
GD350-185G-4
GD350-200G-4
GD350-220G-4
GD350-250G-4
GD350-280G-4
GD350-315G-4
GD350-350G-4
GD350-400G-4
GD350-450G-4
GD350-500G-4
Note:

The rated input voltage drop of input reactors is 2%.

The current adjustment coefficient on the input side of the VFD is higher than 90% after a DC
reactor is configured.

The rated output voltage drop of output reactors is 1%.

The preceding table describes external accessories. You need to specify whether external or
built-in accessories are needed in your purchase order.
VFD model
GD350-022G-6
GD350-030G-6
GD350-037G-6
GD350-045G-6
GD350-055G-6
GD350-075G-6
GD350-090G-6
GD350-110G-6
Table D–8 Reactors for AC 3PH 520V (-15%)–690V (+10%)
Input reactor
ACL2-022-4
ACL2-037-4
ACL2-037-4
ACL2-045-4
ACL2-055-4
ACL2-075-4
ACL2-110-4
ACL2-110-4
ACL2-160-4
ACL2-160-4
ACL2-200-4
ACL2-200-4
ACL2-280-4
ACL2-280-4
ACL2-280-4
ACL2-350-4
Standard
Standard
Standard
Standard
Input reactor
ACL2-030-6
ACL2-030-6
ACL2-055-6
ACL2-055-6
ACL2-055-6
ACL2-110-6
ACL2-110-6
ACL2-110-6
-405-
Optional peripheral accessories
DC reactor Output reactor
Standard
Standard
Standard
Standard
Standard
Standard
Standard
Standard
DCL2-132-4
DCL2-160-4
DCL2-200-4
DCL2-220-4
DCL2-280-4
DCL2-280-4
DCL2-280-4
DCL2-315-4
DCL2-400-4
DCL2-400-4
DCL2-500-4
DCL2-500-4
DC reactor Output reactor
DCL2-030-6
DCL2-030-6
DCL2-055-6
DCL2-055-6
DCL2-055-6
DCL2110-6
DCL2-110-6
DCL2-110-6
OCL2-022-4
OCL2-037-4
OCL2-037-4
OCL2-045-4
OCL2-055-4
OCL2-075-4
OCL2-110-4
OCL2-110-4
OCL2-200-4
OCL2-200-4
OCL2-200-4
OCL2-200-4
OCL2-280-4
OCL2-280-4
OCL2-280-4
OCL2-350-4
OCL2-350-4
OCL2-400-4
OCL2-500-4
OCL2-500-4
OCL2-030-6
OCL2-030-6
OCL2-055-6
OCL2-055-6
OCL2-055-6
OCL2-110-6
OCL2-110-6
OCL2-110-6
