Goodrive350 series high-performance multifunction VFD
Function
Name
code
mode for
asynchronous
motor 1
End frequency
point for
switching off IF
P04.51
mode for
asynchronous
motor 2
P05––Input terminals
Function
Name
code
P05.00 HDI input type
Function of S1
P05.01
terminal
Function of S2
P05.02
terminal
Function of S3
P05.03
terminal
Function of S4
P05.04
terminal
Function of HDIA
P05.05
terminal
Function of HDIB
P05.06
terminal
Description
P04.49–P00.03
Description
0x00–0x11
Ones: HDIA input type
0: HDIA is high-speed pulse input
1: HDIA is digital input
Tens: HDIB input type
0: HDIB is high-speed pulse input
1: HDIB is digital input
0: No function
1: Forward running
2: Reverse running
3: 3-wire control/Sin
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
9: External fault input
10: Frequency increase (UP)
11: Frequency decrease (DOWN)
12: Clear frequency increase/decrease setting
13: Switchover between setup A and setup B
14: Switchover between combination setup and
setup A
15: Switchover between combination setup and
setup B
16: Multi-step speed terminal 1
-166-
Function parameter list
Default
Modify
value
○
25.00Hz
Default
Modify
value
◎
0x00
◎
1
◎
4
◎
7
◎
0
◎
0
◎
0
