INVT Goodrive350 Series Operation Manual page 292

Goodrive350 series high-performance multifunction VFD
Fault
Fault type
code
EEP [21] EEPROM fault
[22] PID feedback
PIDE
offline fault
[23] Braking unit
bCE
[24] Running time is
END
[25] Electronic
OL3
overload fault
[26] Keypad
PCE
communication fault
[27] Parameter
UPE
upload error
[28] Parameter
DNE
download error
R/W error occurred to the
control parameters;
EEPROM is damaged
PID feedback offline;
PID feedback source
disappears;
Braking circuit fault or
braking tube is damaged;
fault The resistance of external
braking resistor is too small
The actual running time of
the VFD is larger than the
up
set running time
The VFD releases overload
pre-alarm based on the set
value
The keypad wire is poorly
contacted or disconnected;
The keypad wire is too long
and suffers strong
interference;
Circuit fault occurred to the
keypad or communication
part of the main board
The keypad wire is poorly
contacted or disconnected;
The keypad wire is too long
and suffers strong
interference;
Circuit fault occurred to the
keypad or communication
part of the main board
The keypad wire is poorly
contacted or disconnected;
The keypad wire is too long
and suffers strong
interference;
Data storage error occurred
to the keypad
Possible cause
-283-
Troubleshooting
Corrective measures
Press STOP/RST to reset;
Replace the main control board
Check PID feedback signal
wires;
Check PID feedback source
Check the braking unit, replace
with new braking tubes;
Increase braking resistance
Ask help from the supplier,
adjust the set running time
Check the load and overload
pre-alarm threshold
Check the keypad wires to
confirm whether fault exists;
Check the surroundings to rule
out interference source;
Replace the hardware and ask
for maintenance service
Check the surroundings to rule
out interference source;
Replace the hardware and ask
for maintenance service;
Replace the hardware and ask
for maintenance service
Check the surroundings to rule
out interference source;
Replace the hardware and ask
for maintenance service;
Re-backup keypad data
