INVT Goodrive350 Series Operation Manual page 249

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Pulse filer
P20.17
processing
Encoder pulse
P20.18
filter width
Pulse reference
P20.19
filter width
Pulse number of
P20.20
pulse reference
Enable angle
P20.21 compensation of
synchronous
Description
0x0000–0xFFFF
Bit0: Enable/disable encoder input filter
0: No filter
1: Filter
Bit1: Encoder signal filter mode (set Bit0 or Bit2 to
1)
0: Self-adaptive filter
1: Use P20.18 filter parameters
Bit2: Enable/disable encoder frequency-division
output filter
0: No filter
1: Filter
Bit3: Enable/disable filter for frequency-division
output of pulse reference
0: No filter
1: Filter
Bit4: Enable/disable pulse reference filter
0: No filter
1: Filter
Bit5: Pulse reference filter mode (valid when Bit4 is
set to 1)
0: Self-adaptive filter
1: Use P20.19 filter parameters
Bit6: Frequency-divided output source setting
(valid only for incremental encoders)
0: Encoder signals
1: Pulse reference signals
Bits7–15: Reserved
0–63
The filtering time is P20.18×0.25 μs. The value 0
or 1 indicates 0.25 μs.
0–63
The filtering time is P20.19×0.25 μs. The value 0
or 1 indicates 0.25 μs.
0–16000
0–1
-240-
Function parameter list
Default
Modify
value
○
0x0033
○
2
○
2
◎
1024
○
0
