Goodrive350 series high-performance multifunction VFD
Function
code
P01.21 Restart after power outage
Waiting time of restart after
P01.22
P01.23
P01.24 Stop speed delay
Open-loop 0Hz output
P01.25
Deceleration time of
P01.26
Time of starting section of
P01.27
deceleration S curve
Time of ending section of
P01.28
deceleration S curve
P01.29 Short-circuit braking current
Hold time of short-circuit
P01.30
braking at startup
Hold time of short-circuit
P01.31
P01.32 Pre-exciting time of jogging
Starting frequency of braking
P01.33
for jogging to stop
P01.34 Delay to enter sleep
P05.01– Digital input function
P05.06
Name
power outage
Start delay
selection
emergency-stop
braking at stop
selection
Description
0: Restart is disabled
1: Restart is enabled
0.0–3600.0s (valid when P01.21 is 1)
0.0–60.0s
0.0–100.0s
0: No voltage output
1: With voltage output
2: Output as per DC braking current of
stop
0.0–60.0s
0.0–50.0s
0.0–50.0s
0.0–150.0% (of rated VFD output current)
0.00–50.00s
0.00–50.00s
0–10.000s
0–P00.03
0–3600.0s
1: Forward running
2: Reverse running
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Running pause
21: Acceleration/deceleration time
selection 1
22: Acceleration/deceleration time
selection 2
30: Acceleration/deceleration disabled
-82-
Basic operation guidelines
Default
value
0
1.0s
0.0s
0.0s
0
2.0s
0.1s
0.1s
0.0%
0.00s
0.00s
0.000s
0.00Hz
0.0s
/
