Goodrive350 series high-performance multifunction VFD
Function
Name
code
standby state
Overvoltage stall
P11.03
protection
Overvoltage stall
P11.04 protection
voltage
Current-limit
P11.05
selection
Automatic
P11.06
current-limit level
Frequency-drop
P11.07 rate during
current limit
Description
1: Disable
0: Disable
1: Enable
DC bus voltage V
Overvoltage stall
threshold
Output
frequency
120–150% (standard bus voltage) (380V)
120–150% (standard bus voltage) (220V)
During accelerated running, as the load is too
large, the actual acceleration rate of motor is lower
than that of output frequency, if no measures are
taken, the VFD may trip due to overcurrent during
acceleration.
0x00–0x11
Ones: Current-limit action selection
0: Invalid
1: Always valid
Tens: Hardware current-limit overload alarm
selection
0: Valid
1: Invalid
Current-limit protection function detects output
current during running, and compares it with the
current-limit level defined by P11.06, if it exceeds
the current-limit level, the VFD will run at stable
frequency during accelerated running, or run in
decreased frequency during constant-speed
running; if it exceeds the current-limit level
continuously, the VFD output frequency will drop
continuously until reaching lower limit frequency.
When the output current is detected to be lower
than the current-limit level again, it will continue
-202-
Function parameter list
Default
Modify
value
○
1
Time t
Time t
136%
○
120%
◎
0x01
G type:
160.0%
◎
P type:
120.0%
10.00
◎
Hz/s
