INVT Goodrive350 Series Operation Manual page 90

Goodrive350 series high-performance multifunction VFD
Function
code
DC braking current before
P01.03
P01.04 DC braking time before start 0.00–50.00s
Acceleration/deceleration
P01.05
P01.08
Starting frequency of DC
P01.09
braking after stop
Waiting time of DC braking
P01.10
P01.11 DC braking current of stop
P01.12 DC braking time of stop
Deadzone time of
P01.13
forward/reverse rotation
Forward/reverse rotation
P01.14
P01.15
P01.16 Stop speed detection mode
Power-on terminal running
P01.18
protection selection
Action selected when
running frequency less than
P01.19 frequency lower limit (valid
when frequency lower limit
P01.20 Wake-up-from-sleep delay
Name
start
mode
Stop mode
after stop
switchover mode
Stop speed
greater than 0)
Description
0.0–100.0%
0: Straight line
1: S curve
Note: If mode 1 is selected, it is required
to set P01.07, P01.27 and P01.08
accordingly
0: Decelerate to stop
1: Coast to stop
0.00Hz–P00.03 (Max. output frequency)
0.00–50.00s
0.0–100.0%
0.00–50.00s
0.0–3600.0s
0: switch over after zero frequency
1: switch over after starting frequency
2: switch over after passing stop speed
and delay
0.00–100.00Hz
0: Set value of speed (the only detection
mode valid in SVPWM mode)
1: Detection value of speed
0: Terminal running command is invalid
at power-on
1: Terminal running command is valid at
power-on
Ones place: Action selection
0: Run at the frequency lower limit
1: Stop
2: Sleep
Tens place: Stop mode
0: Coast to stop
1: Decelerate to stop
0.0–3600.0s (valid when P01.19 is 2)
-81-
Basic operation guidelines
Default
value
0.0%
0.00s
0
0
0.00Hz
0.00s
0.0%
0.00s
0.0s
1
0.50Hz
1
0
0x00
0.0s
