Goodrive350 series high-performance multifunction VFD
Setting
Acceleration/deceleration time
22
23 Simple PLC stop reset
24 Simple PLC pause
25 PID control pause
Wobbling frequency pause
26
(stop at current frequency)
Wobbling frequency reset
27
(revert to center frequency)
28 Counter reset
Switching between speed
29
control and torque control
Acceleration/deceleration
30
31 Counter trigger
Clear frequency
33 increase/decrease setting
34
Switching between motor 1
35
Function
selection 2
disabled
temporarily
DC brake
and motor 2
Terminal Terminal
1 2
Acceleration/
OFF OFF
deceleration time 1
Acceleration/
ON OFF
deceleration time 2
Acceleration/
OFF ON
deceleration time 3
Acceleration/
ON ON
deceleration time 4
Restart simple PLC process and clear previous PLC
state information.
The program pauses during PLC execution, and keeps
running in current speed step. After this function is
cancelled, simple PLC keeps running.
PID is ineffective temporarily, and the VFD maintains
current frequency output.
The VFD pauses at current output. After this function is
canceled, it continues wobbling-frequency operation at
current frequency.
The set frequency of VFD reverts to center frequency.
Zero out the counter state.
The VFD switches from torque control mode to speed
control mode, or vice versa.
Ensure the VFD will not be impacted by external signals
(except for stop command), and maintains current output
frequency.
Enable pulse counting of the counter.
When the terminal is closed, the frequency value set by
UP/DOWN can be cleared to restore to the frequency
given by frequency command channel; when the terminal
is disconnected, it will revert to the frequency value after
frequency increase/decrease setting.
The VFD starts DC braking immediately after the
command becomes valid.
When this terminal is valid, you can realize switchover
control of two motors.
-97-
Basic operation guidelines
Description
Acceleration or
Corresponding
deceleration time
selection
P00.11/P00.12
P08.00/P08.01
P08.02/P08.03
P08.04/P08.05
parameter
