Goodrive350 series high-performance multifunction VFD
Function
code
P05.06 Function of HDIB terminal
Name
-101-
Description
6: Coast to stop
7: Fault reset
8: Running pause
9: External fault input
10: Frequency increase (UP)
11: Frequency decrease (DOWN)
12: Clear frequency
increase/decrease setting
13: Switchover between setup A and
setup B
14: Switchover between combination
setting and A setting
15: Switchover between combination
setting and setup B
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi-step speed pause
21: Acceleration/deceleration time
selection 1
22: Acceleration/deceleration time
selection 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Wobbling frequency pause
27: Wobbling frequency reset
28: Counter reset
29: Switching between speed control
and torque control
30: Acceleration/deceleration
disabled
31: Counter trigger
32: Reserved
33: Clear frequency
increase/decrease setting
temporarily
34: DC brake
Basic operation guidelines
Default
value
0
0
