INVT Goodrive350 Series Operation Manual page 237

Goodrive350 series high-performance multifunction VFD
Function
Name
code
P17.06 Torque current
P17.07 Exciting current
P17.08 Motor power
Motor output
P17.09
torque
Estimated motor
P17.10
frequency
P17.11 DC bus voltage
Digital input
P17.12
terminal state
Digital output
P17.13
terminal state
P17.14 Digital
Description
Range: 0–65535RPM
Display current torque current of the VFD.
Range: -3000.0–3000.0A
Display current exciting current of the VFD.
Range: -3000.0–3000.0A
Display current motor power; 100% relative to
rated motor power, positive value is motoring
state, negative value is generating state.
Range: -300.0–300.0% (relative to rated motor
power)
Display current output torque of the VFD; 100%
relative to rated motor torque, during forward
running, positive value is motoring state, negative
value is generating state, during reverse running,
positive value is generating state, negative value is
motoring state.
Range: -250.0–250.0%
The estimated motor rotor frequency under
open-loop vector condition.
Range: 0.00– P00.03
Display current DC bus voltage of the VFD.
Range: 0.0–2000.0V
Display current digital input terminal state of the
VFD.
0x00–0x3F
Bit0: S1
Bit1: S2
Bit2: S3
Bit3: S4
Bit4: HDIA
Bit5: HDIB
Display current digital output terminal state of the
VFD.
0x00–0x0F
Bit0: Y1
Bit1: HDO
Bit2: RO1
Bit3: RO2
Display the regulating variable by UP/DOWN
-228-
Function parameter list
Default
Modify
value
●
0.0A
●
0.0A
●
0.0%
●
0.0%
●
0.00Hz
●
0V
●
0x00
●
0x00
●
0.00Hz
