Goodrive350 series high-performance multifunction VFD
Function
code
Setting source of
P03.19 braking torque
upper limit
Electromotive
torque upper limit
P03.20
set through
Braking torque
P03.21 upper limit set
through keypad
Motor output
P17.09
Torque reference
P17.15
Name
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET/EtherNet IP
communication
10: Programmable card
11: Reserved
Note: For these settings, 100% corresponds to
the motor rated current.
0: Keypad (P03.21)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus/Modbus TCP communication
6: PROFIBUS/CANopen/DeviceNet
communication
7: Ethernet communication
8: Pulse frequency HDIB
9: EtherCAT/PROFINET/EtherNet IP
communication
10: Programmable card
11: Reserved
Note: For these settings, 100% corresponds to
the motor rated current.
0.0–300.0% (of the motor rated current)
keypad
0.0–300.0% (of the motor rated current)
-250.0–250.0%
torque
-300.0–300.0% (of the motor rated current)
value
Description
-72-
Basic operation guidelines
Default
value
0
180.0%
180.0%
0.0%
0.0%
