INVT Goodrive350 Series Operation Manual page 427

Goodrive350 series high-performance multifunction VFD
Model
GD350-1R5G-4
GD350-2R2G-4
GD350-004G-4
GD350-5R5G-4
GD350-7R5G-4
GD350-011G-4
GD350-015G-4
GD350-018G-4
GD350-022G-4
GD350-030G-4
GD350-037G-4
GD350-045G-4
GD350-045G-4-B(F)
GD350-055G-4
GD350-055G-4-B(F)
GD350-075G-4
GD350-075G-4-B(F)
GD350-090G-4
GD350-090G-4-B(F)
GD350-110G-4
GD350-110G-4-B(F)
GD350-132G-4
GD350-160G-4
GD350-185G-4
GD350-200G-4
GD350-220G-4
GD350-250G-4
GD350-280G-4
GD350-315G-4
GD350-355G-4
GD350-400G-4
GD350-450G-4
GD350-500G-4
Table F–2 Rated specifications
Apparent Rated output
power (kVA) power (kW)
2.4 1.5
3.3 2.2
6.2 4
9.2 5.5
12.2 7.5
16.4 11
21.0 15
25.0 18.5
29.6 22
39.4 30
49.3 37
60.5 45
60.5 45
75.7 55
75.7 55
98.7 75
98.7 75
118.5 90
118.5 90
141.5 110
141.5 110
171.1 132
200.7 160
223.7 185
250.1 200
279.7 220
315.9 250
348.8 280
394.9 315
427.8 355
473.8 400
539.7 450
566.0 500
Max. working
Rated output
temperature
current (A)
(° C)
3.7
5
9.5
14
18.5
25
32
38
45
60
75
92
92
115
50° C
115
Derate by 1% for
150
every increase of
150
1° C when the
180
temperature
180
exceeds 40° C.
215
215
260
305
340
380
425
480
530
600
650
720
820
860
-418-
Energy efficiency data
Rated
Rated power
power
frequency (Hz)
voltage (V)
50Hz/60Hz
Allowed range: 3PH 380V
47–63Hz
