P08 Group Enhanced Functions - INVT Goodrive20-UL VFD Series Operation Manual

Goodrive20-UL Series VFD
Function
Name
code
state at
previous 2
faults

P08 group Enhanced functions

Function
Name
code
ACC time
P08.00
2
DEC time
P08.01
2
ACC time
P08.02
3
DEC time
P08.03
3
ACC time
P08.04
4
DEC time
P08.05
4
Jogging
P08.06 running
frequency
Jogging
P08.07 running
ACC time
Jogging
running
P08.08
DEC time
Jumping
P08.09 frequency
1
Jumping
P08.10 frequency
range 1
Jumping
frequency
P08.11
2
Description
Description
Refer to P00.11 and P00.12 for detailed
definition.
Goodrive20-UL series define four groups of
ACC/DEC time which can be selected by P5
group. The first group of ACC/DEC time is the
factory default one.
Setting range: 0.0–3600.0s
This parameter is used to define the reference
frequency during jogging.
Setting range: 0.00Hz–P00.03 (Max. output
frequency)
The jogging ACC time means the time needed if
the VFD runs from 0Hz to the Max. Frequency.
The jogging DEC time means the time needed if
the VFD goes from the Max. Frequency
(P00.03) to 0Hz.
Setting range: 0.0–3600.0s
When the set frequency is in the range of
jumping frequency, the VFD will run at the edge
of the jumping frequency.
The VFD can avoid the mechanical resonance
point by setting the jumping frequency. The VFD
can set three jumping frequency. But this
function will be invalid if all jumping points are 0.
-72-
Function parameters
Default Modify
Default Modify
Depend
○
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
Depend
○
on model
○
5.00Hz
Depend
○
on model
Depend
○
on model
○
0.00Hz
○
0.00Hz
○
0.00Hz
