INVT Goodrive350 Series Operation Manual page 233

Goodrive350 series high-performance multifunction VFD
Function
Name
code
Communication
timeout period of
P16.28
expansion card in
card slot 2
Communication
timeout period of
P16.29
expansion card in
card slot 3
Reserved
P16.30
PROFINET
P16.31
communication
timeout time
P16.32 Received PZD2 0–31
P16.33 Received PZD3
Received PZD4
P16.34
Received PZD5
P16.35
Received PZD6
P16.36
Received PZD7
P16.37
Received PZD8
P16.38
Received PZD9
P16.39
P16.40 Received PZD10
P16.41 Received PZD11
P16.42 Received PZD12
Description
0.0–600.0s
If it is set to 0.0, offline fault will not be detected.
0.0–600.0s
If it is set to 0.0, offline fault will not be detected.
/
0.0–60.0s
0: Invalid
1: Set frequency (0–Fmax. Unit: 0.01Hz)
2: PID reference (-1000–1000, in which 1000
corresponds to 100.0%)
3: PID feedback (-1000–1000, in which 1000
corresponds to 100.0%)
4: Torque setting (-3000–+3000, in which 1000
corresponds to 100.0% of the motor rated current)
5: Setting of the upper limit of forward running
frequency (0–Fmax. Unit: 0.01 Hz)
6: Setting of the upper limit of reverse running
frequency (0–Fmax. Unit: 0.01 Hz)
7: Upper limit of electromotive torque (0–3000, in
which 1000 corresponds to 100.0% of the motor
rated current)
8: Upper limit of braking torque (0–3000, in which
1000 corresponds to 100% of the motor rated
current)
9: Virtual input terminal command (Range: 0x000–
0x3FF, corresponding to
S8/S7/S6/S5/HDIB/HDIA/S4/S3/S2/S1)
10: Virtual output terminal command (Range:
0x00–0x0F, corresponding to RO2/RO1/HDO/Y1)
11: Voltage setting (special for V/F separation)
(0–1000, in which 1000 corresponds to 100% of
the motor rated voltage)
-224-
Function parameter list
Default
Modify
value
○
0.0s
○
0.0s
/
/
○
5.0s
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
○
0
