Goodrive300-01A series VFD for air compressor

5.1 Function parameter list

"○" indicates that the value of the parameter can be modified when the VFD is in stopped or running
state.
"◎" indicates that the value of the parameter cannot be modified when the VFD is in running state.
"●" indicates that the value of the parameter is the actually detected value which cannot be modified.
(The VFD automatically checks and constrains the modification of parameters, which helps prevent
incorrect modifications.)

P00 group Basic functions

Function
Name
code
Speed control
P00.00
mode
Channel of
P00.01 running
commands
Communication
mode of
P00.02
running
commands
Max. output
P00.03
frequency
Upper limit of
P00.04 running
frequency
Lower limit of
P00.05 running
frequency

5 Function description

Description
0: SVC mode 0 (applicable to AM, SM)
1: SVC mode 1(applicable to AM)
2: V/F control
Note:
AM: Asynchronous Motor;
SM: Synchronous Motor;
If vector mode is adopted, it is a must to carry
out motor parameter autotuning on the VFD
first.
0: Keypad (LED off)
1: Terminal (LED blinks)
2: Communication (LED on)
0: Modbus communication
1–3: Reserved
P00.04–400.00Hz
P00.05–P00.03 (max. output frequency)
0.00Hz–P00.04 (upper
frequency)
-35-
limit of running
Function description
Default Modify
◎
0
○
0
○
0
◎
50.00Hz
○
50.00Hz
○
0.00Hz
