7
8
1 Disabled
1 Disabled
Table 60 describes the fields in this display.
Table 60 Output for display spantree
Field
VLAN
Spanning tree mode
Spanning tree type
Spanning tree
enabled
Designated Root
Designated Root
Priority
Designated Root Path
Cost
Designated Root Port Port through which this WX switch reaches the root bridge.
Root Max Age
Root Hello Time
Root Forward Delay
Bridge ID MAC ADDR This WX switch's MAC address.
Bridge ID Priority
Bridge Max Age
Bridge Hello Time
Bridge Forward Delay This WX switch's forwarding delay value.
Port
Vlan
19 128
19 128
Description
VLAN number.
In the current software version, the mode is always PVST+,
which means Per VLAN Spanning Tree+.
In the current software version, the type is always IEEE,
which means MSS STP is 802.1D-compatible.
State of STP on the VLAN.
MAC address of the spanning tree's root bridge.
Bridge priority of the root bridge.
Cumulative cost from this bridge to the root bridge. If this
WX switch is the root bridge, then the root cost is 0.
If this WX switch is the root bridge, this field says We are
the root.
Maximum acceptable age for hello packets on the root
bridge.
Hello interval on the root bridge.
Forwarding delay value on the root bridge.
This WX switch's bridge priority.
This WX switch's maximum acceptable age for hello
packets.
This WX switch's hello interval.
Port number.
Only network ports are listed. STP does not apply to 3Com
Wireless LAN Managed Access Point AP2750 ports or wired
authentication ports.
VLAN ID.
display spantree
Disabled
Disabled
