BCM5718 Programmer's Guide
Block Name Block Range
HC 0x3C00–0x3FFF
MA 0x4000–0x43FF
BM 0x4400–0x47FF
DMAR 0x4800–0x4BFF
DMAW 0x4C00 -0x4FFF
RX-CPU 0x5000–0x53FF
VRQ Filter–EMAC 0x5400–0x57FF
MB 0x5800–0x5BFF
FTQ 0x5C00–0x5FFF
MSI 0x6000–0x63FF
CFG Port 0x6400–0x67FF
GRC 0x6800–0x6BFF
ASF 0x6C00–0x6FFF
NVM 0x7000–0x73FF
UART 0x7800–0x7BFF
TL-DL-PL Port 0x7C00–0x7FFF
Registers below are outside Host Standard View
APE 0x10000–0x18FFF
MF 0x19000–0x193FF
Broadcom
®
January 29, 2016 • 5718-PG108-R
Table 158: BCM5717 / BCM5718 Register Map (Cont.)
Sub-Block Range
0x3C00–0x3CC3
0x3CC4–0x3FFF
0x4000–0x400F
0x4010–0x43FF
0x4400–0x445B
0x445C–0x47FF
0x4800–0x4910
0x4A00–0x4AFF
0x4B00–0x4BFF
0x4C00–0x4C07
0x4C08–0x4FFF
0x5000–0x5037
0x5038–0x53FF
0x5400–0x55FF
0x5600–0x568F
0x5690–0x572F
0x5730–0x57FF
0x5800–0x5903
0x5903–0x5BFF
0x5C00–0x5CFF
0x5D00–0x5FFF
0x6000–0x6007
0x6008–0x63FF
0x6400–0x67FF
0x6800–0x681B
0x6834–0x6843
0x6890–0x68A8
0x68B4–0x68EF
0x6C00–6C37
0x6C38–0x6FFF
0x7000–0x703B
0x703C–0x73FF
0x7800–0x781F
0x7820–0x7BFF
0x7C00–0x7FFF
–
–
BCM5717 / BCM5718 Register Map
Description
Host Coalescing
Multiqueue HC
Memory Arbiter
Unused
Buffer manager
Unused
DMAR LSO channel
DMAR BD channel
DMAR non-LSO channels
DMA Write
Unused
RX CPU
Unused
VRQ Filter Set
VRQ Mapper
VRQ Perfect Match Registers
Unused
Low Priority Mail Box
Unused
Flow Through Queue
Unused
Message Signaled Interrupt
Unused
PCIe Core Private Registers Access to
Configuration Space
Misc Host Control
SEEPROM
Misc Control
E Switch
ASF & SMBUS
Unused
Non Volatile memory (Flash Controller)
Unused
Debug UART Modem
Unused
PCIe Core Private Register Access to TL,
DL & PL
APE Access
Management Filters
