BCM5718 Programmer's Guide

Memory Data Register (offset: 0x84)

Name
Memory Base Register
UNDI Receive Return Ring Consumer Index Register (offset: 0x88–
0x8C)
Name
UNDI Receive Return C_Idx
UNDI Send BD Producer Index Mailbox Register (offset: 0x90–0x94)
Name
UNDI Send BD NIC P_Idx
UNDI Receive BD Standard Producer Ring Producer Index Mailbox
Register (offset: 0x98–0x9C)
Name
UNDI Receive BD Standard
Ring Producer Index
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
31:0 RW X
Default
Bits Access Value
63:0 RW 0
Default
Bits Access Value
63:0 RW 0
Default
Bits Access Value
63:0 RW 0
Description
Memory value at the location pointed by the
Memory Base Register
Description
UNDI Receive Return Ring Consumer Index
Mailbox
Description
UNDI Send BD NIC Producer Index Mailbox
Description
UNDI Receive BD Std. Ring Producer Index
Mailbox
PCI Configuration Registers
Page 287
