BCM5718 Programmer's Guide
Name
WOL Magic Packet Detection
Enable Status of Port 1
Ethernet link status
Link idle status
GPHY DLL lock status
NCSI DLL lock status
WOL ACPI Detection Enable
Status of Port 0
WOL Magic Packet Detection
Enable Status of Port 0
VMAIN power status
Reserved
Power State
Energy Detect Status
CPMU Power State
Power Management State
Machine State
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
21 RO –
20:19 RO –
18 RO –
17 RO –
16 RO –
15 RO –
14 RO –
13 RO –
12:10 DC 0x0
9:8 RO –
7 RO –
6:4 RO –
3:0 RO –
Central Power Management Unit (CPMU) Registers
Description
1: Magic Packet Detection enabled
0: Magic Packet Detection disabled
EthernetLink Status
11: no link
10: 10 Mb
01: 100 Mb
00: 1000 Mb
Link Idle status
1: Idle
0: Active
1: Locked
0: Not locked
1: Locked
0: Not locked
1: ACPI detection enabled.
0: ACPI detection disabled.
1: Magic Packet Detection Enabled.
0: Magic Packet Detection Disabled.
VMAIN Power Status
1: On
0: Off
–
Device Power State Status.
11: D3
00: D0
Energy Status
1: On
0: Off
Indicates the current power state of the CPMU.
Indicates the current state of hardware power
management state machine.
