Name
Flash Clock Speed Override
Enable
Reserved
Force Flash Clock Disable
Reserved
Force APE FCLK Disable
Force APE HCLK Disable

Status Register (offset: 0x362C)

This register is reset by POR Reset or CPMU Register Software Reset.
Name
Reserved
FUNC_NUMBER
FUNC_ENABLE
APE status
WOL ACPI Detection Enable
Status of Port 1
Broadcom
®
January 29, 2016 • 5718-PG108-R
Default
Bits Access Value
11 RW 0x0
10:7 DC 0x0
6 RW 0x0
5:2 DC 0x0
1 RW 0x0
0 RW 0x0
Default
Bits Access Value
31 RO –
31:30 RO 0x0
29:25 RO –
24:23 RO –
22 RO –
Central Power Management Unit (CPMU) Registers
Description
Enable Flash clock override*.
1: Enable
0: Disable
–
Flash clock Disable*.
1: Disable Flash clock
0: Enable Flash clock
–
APE FCLK clock Disable*.
1: Disable APE FCLK clock
0: Enable APE FCLK clock
APE HCLK Disable*.
1: Disable APE HCLK clock
0: Enable APE HCLK clock
Description
For 5719 four port devices, the bit31 will be used
by FUNC_NUMBER. For 5718/5720 two port
devices will not.
PCIE function number 1: function number
3: function 3
2: function 2
1: function 1
0: function 0
Note: CPMU port0 is tied to function 0, CPMU
port1 is tied to function1.
CPMU port2 is tied to function2.
CPMU port3 is tied to functiion3.
Function Enable input from System BIOS.
APE Engine Status
11: Reserved
10: Deep Sleep State
01: Sleep State
00: Active State
1: ACPI detection enabled
0: ACPI detection disabled
