Broadcom NetXtreme/NetLink BCM5718 Series Programmer's Manual page 518

BCM5718 Programmer's Guide
Bit Name
8 Disable Auto Encoding
Correction
7 Old PCS Encoding RX
6 Old PCS Encoding TX
5 Enable EC as NEXT
4 Enable force_mdix
3 En_PWRDNTDAC
2:0 SHADOW REGISTER
SELECTOR
(REFERENCE ONLY)
Broadcom
®
January 29, 2016 • 5718-PG108-R
RW Description
RW 0 = Autoencoding correction enabled (overrides
bits 6 and 7)
1 = Autoencoding correction disabled
RW 0 = Select IEEE compliant PCS encoding (for
PCS receive)
1 = Select old PCS encoding (for PCS receive)
RW 0 = Select IEEE compliant PCS encoding (for
PCS receive)
1 = Select old PCS encoding (for PCS receive)
RW 1 = enable, 0 = disable
RW 1 = enable, 0 = disable
RW 1 = enable, 0 = disable
RW Writes to the selected shadow register are done
on a single cycle (no setup required).
Reads are selected by first writing to register
18h, shadow 7, bits 14:12.
10h–1Fh Register Map Detailed Description
Default
0
0
0
0
0
0
101
Page 518
